C&K JCHZ-100 manual horizontal vertical stage standard models

Manual Linear Positioner (100mm Crossed-Roller Guide Platform)

Featuring a generously sized 100×100 mm mounting table, the JCHZ-100 manual linear positioner incorporates high-precision crossed-roller bearings and a fine-pitch vernier drive mechanism to deliver smooth, accurate single-axis motion. Constructed from solid aluminum and weighing 1 kg, this stage combines structural rigidity with manageable mass, making it suitable for both standalone bench use and integration into larger multi-axis positioning systems. It provides a linear travel of ±5 mm and supports installation in either horizontal or vertical alignment, offering engineers flexible mounting options for optical, industrial and scientific instrumentation projects.

Equipped with a 10 μm vernier scale resolution, a 100 μm table parallelism rating and a 30 μm drive parallelism tolerance, the JCHZ-100 maintains consistent geometric accuracy throughout its full range of movement. It is widely implemented in machine vision setups, optical inspection stations, microscopy positioning, precision bonding equipment and semiconductor handling fixtures. The expansive 100 mm platform surface easily accommodates multiple components, custom adapters and larger optical elements, providing a stable foundation for applications that demand both generous working area and dependable micron-level adjustment capability.

This model represents a strong balance between load capacity, platform size and overall affordability. The black anodized finish ensures long-term wear resistance and reduces stray light interference in optical environments, while the 8 kgf load-bearing capacity handles substantial payloads including camera assemblies, lens systems and custom tooling without compromising motion quality. For manufacturers and research teams seeking a durable, manually adjusted positioning solution with ample workspace and reliable performance, the JCHZ-100 offers compelling overall value.

Our company operates as a Sino-Korean joint manufacturing venture located in Dongguan, Guangdong — at the heart of China's advanced precision engineering sector. Leveraging a comprehensive local supply infrastructure, decades of accumulated machining know-how and strict ISO-aligned quality procedures, every unit is individually tested for travel smoothness, dimensional accuracy and load stability before dispatch. With scalable production capacity and dedicated technical support available for custom modifications, we warmly welcome customers to visit our facilities and explore long-term partnership possibilities.
