Manual Precision Stage (Crossed-Roller Guide 80mm Platform Model)

The JCHZ-80 is a heavy-duty manual linear stage built around a robust crossed-roller bearing system with vernier micrometer drive, presenting an 80×80 mm working surface for mounting larger optical and mechanical components. Its solid aluminum construction gives it a stable base weighing 0.55 kg, while still maintaining a space-efficient form factor ideal for both benchtop laboratory setups and integrated production machinery. Offering a total travel distance of ±5.0 mm along a single axis, this stage can be installed in either horizontal orientation and readily stacked into multi-axis assemblies for XYZ positioning configurations.

With a vernier resolution of 10 μm, an 80 μm surface parallelism specification and a 30 μm driving parallelism tolerance, this stage delivers consistent, backlash-free motion and dependable positional accuracy across its entire 10 mm total stroke. It finds broad application in laser alignment systems, CCD camera positioning, optical component mounting, precision dispensing equipment and metrology workstations. The larger platform area accommodates bigger fixtures and multi-component arrangements, making it particularly well-suited for research laboratories, quality control departments and automated inspection lines that require stable, repeatable fine-positioning capability.

This JCHZ-80 model delivers exceptional utility and performance value. The black anodized aluminum body provides excellent corrosion resistance and minimizes unwanted optical reflections, while the 5 kgf load capacity comfortably supports heavier optical assemblies and custom tooling. For system integrators and equipment builders seeking a manually driven positioning solution with generous mounting space and solid mechanical performance at an accessible price point, this stage stands out as a highly cost-effective selection.
